COMPA OMS 300 T Professional Miter Saw User Manual

1. Sigurnosne informacije

Uvijek dajte prioritet sigurnosti pri radu s električnim alatima. Nepoštivanje ovih uputa može dovesti do ozbiljnih ozljeda ili oštećenja alata.

• Zaštita očiju: Always wear approved safety glasses or goggles to protect against flying debris.
• Zaštita ruku: Keep hands and fingers clear of the blade path at all times. Use push sticks or clamps kada je potrebno.
• Sigurnost radnog komada: Uvjerite se da je obradak sigurno clamped before making any cuts. Never hold the workpiece freehand.
• Prekid napajanja: Disconnect the saw from the power supply before performing any assembly, adjustments, maintenance, or when changing blades.
• Radno područje: Maintain a clean, well-lit, and uncluttered work area. Keep children and bystanders away.
• Pravilna ventilacija: Operate the saw in a well-ventilated area, especially when cutting materials that produce fine dust.
• Pročitajte priručnik: Read and understand the entire instruction manual before operating the miter saw.

2. Proizvod je gotovview

The COMPA OMS 300 T Professional Miter Saw is a precise, reliable, and robust yet lightweight tool designed for durability and efficient cutting of wood and metal. It features an intuitive angle locking and unlocking system for quick and accurate adjustments, an induction motor with built-in protection, and a sliding fence for perfect 90° and 45° inclinations. The machine includes pre-drilled holes for secure workbench mounting and a robust upper fence for versatile cutting, including extremely thin strips.

Ključne karakteristike:

• Induction Motor with Protection
• Single-movement Angle Locking and Unlocking System
• Sliding Fence for Precise Angle Cuts
• Robust Upper Fence with Two Fixing Positions
• Integrated Brake System
• Automatic Cutting Angle Lock (90°, 45°, 30°, 22.5°, 15°)

3. Komponente i kontrole

Familiarize yourself with the various components and controls of your COMPA OMS 300 T miter saw for safe and effective operation.

This image displays several key features of the miter saw. Top left shows the 'Sacco raccogli segatura' (dust collection bag) for a cleaner workspace. Top right illustrates the 'Esclusiva doppia squadretta scorrevole' (exclusive double sliding fence) for enhanced material support and precision. Bottom left highlights the 'Squadra superiore con lato a 45°' (upper fence with 45° side) for specialized cuts. Bottom right demonstrates the 'Bloccaggio automatico dell'angolo di taglio a: 90° 45° 30° 22.5° 15°' (automatic cutting angle lock) for quick and accurate angle adjustments.

• Vrećica za skupljanje prašine: Attaches to the saw to collect sawdust, keeping the work area cleaner.
• Double Sliding Fence: Provides adjustable support for the workpiece, crucial for accurate miter cuts.
• Upper Fence: Offers additional support for taller workpieces and can be adjusted for specific cutting requirements, including a 45° side.
• Automatic Angle Lock: Allows for quick and precise setting of common cutting angles (90°, 45°, 30°, 22.5°, 15°).
• Kut Clamp: Used to firmly secure the workpiece to the saw table, preventing movement during cutting.

4. Postavljanje

Proper setup is essential for safe and accurate operation of your miter saw.

1. Raspakiranje: Carefully remove the saw and all accessories from the packaging. Inspect for any shipping damage. Report any damage immediately to your dealer.
2. Montaža: Securely fasten the miter saw to a stable, level workbench using the pre-drilled holes in the saw's base. Use appropriate bolts and washers to prevent any movement during operation.
3. Priprema radnog prostora: Ensure your work area is well-lit, free of clutter, and has sufficient space for the workpiece and safe operation.
4. Skupljanje prašine: Attach the dust collection bag or connect the saw to a suitable dust extraction system to manage sawdust.
5. Priključak za napajanje: Connect the saw to a grounded power outlet that matches the voltage and frequency specifications of the tool.

5. Upute za rad

Follow these steps for safe and effective operation of your COMPA OMS 300 T miter saw.

5.1 Basic Straight Cuts (90° Miter, 0° Bevel)

1. Ensure the saw is set to a 90° miter angle and 0° bevel angle.
2. Čvrsto postavite obradak uz ogradu i na stol pile.
3. Secure the workpiece with the angle clamp spriječiti kretanje.
4. Pokrenite motor i pustite da oštrica postigne punu brzinu.
5. Polako i ravnomjerno spuštajte list pile kroz radni komad. Nemojte silom rezati.
6. Once the cut is complete, allow the blade to stop spinning before raising the saw head.

5.2 Miter Cuts (Angle Cuts)

1. Release the miter lock and adjust the saw table to the desired miter angle (e.g., 45°). Use the automatic angle lock for common angles.
2. Lock the miter angle securely.
3. Položaj i klamp the workpiece as described for basic cuts.
4. Proceed with the cut, ensuring a smooth and controlled motion.

5.3 Bevel Cuts (Angled Blade Cuts)

1. Release the bevel lock and tilt the saw head to the desired bevel angle (up to 45°).
2. Lock the bevel angle securely.
3. Položaj i klamp the workpiece. Be aware that the cutting capacity may change with bevel angles.
4. Make the cut carefully, maintaining control of the saw head.

6. Održavanje

Regular maintenance ensures the longevity and optimal performance of your miter saw. Always disconnect the saw from the power supply before any maintenance.

• Čišćenje: After each use, clean the saw thoroughly to remove sawdust and debris. Pay special attention to the motor vents, blade guard, and moving parts. Use compressed air if available.
• Promjene oštrice:
  1. Isključite napajanje.
  2. Refer to the saw's specific instructions for accessing the blade.
  3. Use the provided wrench to loosen the blade retaining nut.
  4. Pažljivo uklonite staru oštricu.
  5. Install the new blade, ensuring the teeth are oriented correctly for cutting.
  6. Tighten the blade retaining nut securely.
  7. Only use blades with a 300mm diameter and 30mm bore.
• Podmazivanje: Periodically check moving parts for smooth operation. Apply a light machine oil to pivot points and sliding mechanisms as needed, avoiding contact with electrical components.
• Inspekcija: Regularly inspect the power cord for damage, the blade for sharpness and cracks, and all fasteners for tightness. Replace worn or damaged parts immediately.

7. Rješavanje problema

Ovaj odjeljak obrađuje uobičajene probleme s kojima se možete susresti pri korištenju ugaone pile.

8. Tehničke specifikacije

Detailed technical data for the COMPA OMS 300 T Professional Miter Saw.

This image illustrates key technical data and cutting capabilities. It shows maximum cutting dimensions at various angles (X=400 Y=285 H=50 MM for 300T, X=150 Y=70 mm at 90°, X=100 Y=70 mm at 45° miter, X=150 Y=45 mm at 45° bevel), blade specifications (D 300 - d 30 mm), motor type (Induction Motor), power (1400 Watt), RPM (2890 G/1'), machine dimensions (700x580x500 mm), and weight (24 Kg).

• Marka: COMPA
• Model: OMS 300 T
• Vrsta motora: Indukcijski motor
• Vlast: 1400 vat
• No-Load Speed (RPM): 2890 G/1' (revolutions per minute)
• Promjer oštrice: 300 mm
• Provrt oštrice: 30 mm
• Max Cutting Capacity (90° Miter, 0° Bevel): 150 mm (širina) x 70 mm (visina)
• Max Cutting Capacity (45° Miter, 0° Bevel): 100 mm (širina) x 70 mm (visina)
• Max Cutting Capacity (0° Miter, 45° Bevel): 150 mm (širina) x 45 mm (visina)
• Max Cutting Capacity (Specific for 300T): 400 mm (X) x 285 mm (Y) x 50 mm (H)
• Težina: 24 kg
• Dimenzije (DxŠxV): 700 mm x 580 mm x 500 mm
• Izvor napajanja: Električni na kabel
• Materijal oštrice: Visoko ugljični čelik
• Preporučene površine: Drvo i metal
• Posebne karakteristike: Brake, Automatic Angle Lock, Sliding Fence
• Uključene komponente: Kut Clamp

9. Jamstvo i podrška

This COMPA OMS 300 T Professional Miter Saw is covered by a limited warranty. For detailed information regarding warranty terms, conditions, and duration, please refer to the warranty card included with your product or contact COMPA customer service.

For technical support, service inquiries, or to purchase replacement parts, please contact COMPA customer service or your authorized dealer. Keep your original purchase receipt as proof of purchase for any warranty claims.
